Specifications:
model | LHP-10H | LHP-100H | LHP-100H |
Flow range | 0.1~10mL/min | 0.1~100mL/min | 0.1~100mL/min |
Pump head material | 316L | 316L | 316L |
withstand voltage | 40MPa | 40MPa | 25MPa |
Long-term work pressure | ≤35MPa | ≤35MPa | ≤20MPa |
Traffic accuracy | ±1% | ±2% | ±2% |
Traffic setting accuracy | 0.1mL/min | 0.1mL/min | 0.1mL/min |
Into / out of the pipeline | 1 / 8,1 / 4 inch | 1 / 8,1 / 4 inch | 1 / 8,1 / 4 inch |
CI | RS232 | RS232 | RS232 |
Product features:
Operation mode: touch screen operation, software control, easy to operate;
Software interface: real-time view of the flow rate, pressure, cumulative flow and other parameters;
Delivery mode: constant current transmission and constant pressure transmission mode are optional;
Pressure range: 0-40MPa (higher pressure can be customized), resolution: 0.1MPa;
Flow range: 0-100 ml/min adjustable, adjustment accuracy: 0.1 ml/min;
Pressure limit: the software has the function of setting pressure limit, and the pressure pump automatically stops working;
Case design: strong corrosion-resistant box, desktop placement, save space.
After-sales service: one-year warranty and lifelong technical support after acceptance;
Operation mode: touch screen operation, software control, easy to operate;
Software interface: real-time view of the flow rate, pressure, cumulative flow and other parameters;
Delivery mode: constant current transmission and constant pressure transmission mode are optional;
Pressure range: 0-40MPa (higher pressure can be customized), resolution: 0.1MPa;
Flow range: 0-100 ml/min adjustable, adjustment accuracy: 0.1 ml/min;
Pressure limit: the software has the function of setting pressure limit, and the pressure pump automatically stops working;
Case design: strong corrosion-resistant box, desktop placement, save space.
After-sales service: one-year warranty and lifelong technical support after acceptance;
